The MeB project, resulted from the collaboration between the Scuola Normale Superiore and the Bargello Museums. Its main objective was the development of shared, applied research, aimed at the modernization of the scientific analysis processes and art-historical study of small-scale metal production of the Early Modern age. Moreover, it aimed at elaborating new operational solutions of potential interest for similar cultural contexts, also throughout the use of 3D laser scans.

2024-11-29T16:32:24+00:0020 June 2023|

METHOD FOR PROCESSING MULTI-PASS RADAR DATA FOR SENSING AND ANALYSING MULTIPLE COMPONENTS OF NON-STATIONARY SCATTERERS

The invention refers to a method of processing interferometric image radar data, acquired in multi-pass configurations, for the detection and analysis of multiple components of non-stationary radio backscatter at different altitudes and/or displacement speeds.

2024-10-25T13:41:27+00:0029 September 2021|

FIELD-EFFECT TRANSISTOR WITH TWO-DIMENSIONAL CHANNEL REALIZED WITH LATERAL HETEROSTRUCTURES BASED ON HYBRIDIZED GRAPHENE

The present invention is a field-effect transistor with a two-dimensional channel consisting of a thin sheet of one or more atomic layers of lateral heterostructures based on hybridized graphene.

2024-10-25T13:41:27+00:0029 September 2021|

Photonic Circuits Diagnosis

The invention is part of the technical sector of optical equipment for the characterization and diagnostics of integrated photonic circuits, that is, all those circuits capable of producing, propagating and manipulating optical signals that can be used for multiple applications, from sensors to telecommunications.

2024-10-25T13:41:39+00:0022 June 2021|
